Product highlights:

General features:

• digital multimedia receiver with AM/FM tuner (does not play discs)

• 7" capacitive touchscreen

• high-resolution (1280x720 pixels) display

• fits in double-DIN (4" tall) dash openings

• HD Radio tuner built-in

• Bluetooth hands-free calling and audio streaming (external microphone included)

Smartphone features:

• Apple CarPlay compatible (wired and wireless)

• Android Auto compatible (wired and wireless)

• built-in iPod, iPhone, and iPad control

• playback and control of music files on compatible Android devices

• Pandora and Spotify control with iPhone and Android

• full Tidal integration with custom display (requires a wi-fi connection and Tidal smartphone app)

Audio/video features:

• plays MP3, WMA, AAC, APE, and FLAC music files (see Details tab for full capabilities)

• plays AVC, FLV, H,264, MP4, MPEG-4, and MOV video files

• plays lossless FLAC audio files up to 96kHz/24-bit

• 24-bit digital-to-analog converter (DAC)

• 13-band parametric equalizer (Basic or Advanced)

• 6-channel time correction

• high- and low-pass filters

• Bass Engine SQ

• MediaXpander HD

Expandability:

• works with SiriusXM SXV300 tuner—supports Tune Mix, Traffic & Weather Now, and Sports Flash features

• compatible with optional Halo wireless level controller

• compatible with optional 2-camera switcher

• inputs: 2 rear USB ports; rear HDMI input; rear auxiliary input; 2 proprietary camera inputs (one composite video adapter is included for non-Alpine cameras)

• outputs: rear HDMI output; 6-channel preamp outputs (4-volt front, rear, subwoofer)

Other information:

• wired connection to parking brake required to access settings, video display, and other features on this receiver (the parking brake must be connected and set, released, and set again)

• built-in internal amp (16 watts RMS CTA-2006/50 peak x 4 channels)

• compatible with most factory steering wheel audio controls (adapter required)

• CTA-2006 compliant

• compatible with iDatalink Maestroretains factory features in a wide selection of vehicles
  displays engine performance data on touchscreen

• warranty: 1 year

• MFR # ILX-507
